Zain Fittings stands out as a top manufacturer and supplier of SMO 254 Forged Fittings, proudly based in Surabaya, Indonesia. The company has built a solid reputation for crafting high-quality forged fittings that excel in corrosion resistance, strength, and durability, especially in tough environments. SMO 254 is a super austenitic stainless steel alloy, rich in chromium, molybdenum, and nitrogen, which gives it remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking, particularly in chloride-heavy and acidic settings. Zain Fittings provides an extensive selection of SMO 254 forged fittings, including elbows, tees, reducers, caps, and couplings, serving industries like chemical, petrochemical, marine, and pharmaceuticals.
| 254 Forged Fittings Specifications | ASTM A182/ ASME SA182 |
|---|---|
| 254 SMO Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| 6 Moly Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| SMO 254 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM A182 SMO 254 Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| SMO 254 Forged Fittings Thread | NPT, BSPT, BSPP |
| SMO 254 Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SMO 254 Forged Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Grade | Ni | Cr | Mo | Cu | N | C | Mn | Si | P | S |
| SMO 254 | 17.5 – 18.5 | 19.5 – 20.5 | 6 – 6.5 | 0.5 – 1 | 0.18 – 0.22 | 0.02 max | 1 max | 0.8 max | 0.03 max | 0.01 max |
| Density | Melting Point | Tensilee Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1320-1390 ℃ | 650 | 300 | 35 % |
These SMO 254 Forged Fittings are made up of about 20–22% chromium, 18–20% nickel, 6–7% molybdenum, and 0.2–0.5% nitrogen, all of which boost their corrosion resistance and mechanical strength. They boast a tensile strength of around 700 MPa, a yield strength of 300 MPa, and an elongation of 30%, along with impressive toughness and ductility. The alloy’s ability to resist pitting and crevice corrosion remains strong, even in harsh chloride and acidic conditions. The forged construction guarantees a consistent microstructure, outstanding mechanical properties, and high reliability, even under high-pressure and high-temperature situations.
Zain Fittings is a leading supplier of SMO 254 Forged Fittings in Jakarta, Indonesia. We offer an extensive range of SMO 254 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| SMO 254 | 1.4547 | S31254 | SIS 2378 | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
| ASTM A182 / A182M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic SMO Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | SMO fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
Choose SMO 254 Forged Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
SMO 254 Forged Fittings offer many advantages, including exceptional corrosion resistance, especially in high chloride environments, making them ideal for marine, chemical and petrochemical applications Their high molybdenum and chromium content pitting, cracking corrosion and stress corrosion cracks Provides excellent strength for . These fittings also exhibit good strength and durability, ensuring high tensile strength and yield strength, long-term performance in harsh conditions Furthermore, SMO 254 mesh fittings offer excellent weldability and formability, making them versatile for a wide range of industrial applications, providing reliability and cost – efficiency.
Yes, custom sizes for SMO 254 Forged Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id
SMO 254 Forged Fittings are a go-to choice in industries that require high-performance, corrosion-resistant piping solutions. They’re perfect for chemical and petrochemical plants, seawater handling systems, desalination units, and heat exchangers. Their exceptional resistance to chloride-induced corrosion makes them ideal for marine applications, the pulp and paper industry, and pharmaceutical equipment. Plus, these fittings find their place in power generation, wastewater treatment, and various other industrial applications, ensuring long-lasting durability, operational safety, and efficient performance in challenging and aggressive environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
