Zain Fittings, located in Surabaya, Indonesia, stands out as a top manufacturer and supplier of premium **180° Long Radius Elbows** and **180° Short Radius Elbows**. These fittings are expertly crafted to facilitate precise directional changes in piping systems, all while ensuring reliability, durability, and optimal performance even under high pressure and temperature conditions. Zain Fittings is committed to meeting international standards, employing advanced manufacturing techniques and strict quality control measures. The company caters to various industries, including oil and gas, petrochemical, power generation, and chemical processing, providing elbows that enhance flow, minimize turbulence, and guarantee long-term efficiency in critical industrial pipelines.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 180° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 180° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 180° Long Radius Elbow
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 180° Short Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 180° Short Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 180° Short Radius Elbow
180° Long Radius and 180° Short Radius Elbows are manufactured using robust materials like stainless steel, carbon steel, and alloys such as Duplex and Super Duplex steel. Their composition includes essential elements like chromium (16-25%), nickel (8-14%), and molybdenum (2-4%), offering excellent corrosion resistance and durability. Mechanical properties include high tensile strength (500-900 MPa), yield strength (250-700 MPa), and good elongation (20-30%), ensuring they withstand high pressures and temperatures. The Long Radius Elbow provides gradual directional changes with reduced turbulence, while the Short Radius Elbow suits tight spaces, maintaining flow efficiency.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
Stainless Steel 180° Short Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 180° Short Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 180° Short Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 180° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 180° Short Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 180° Short Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 180° Short Radius Elbow : ASTM A420 WPL3, A420 WPL6
The **180° Long Radius Elbows** boast a curvature radius that is 1.5 times the pipe diameter, promoting smoother flow with minimal pressure loss. They are perfect for systems that require gradual directional shifts to lessen fluid turbulence and energy waste. These elbows come in a range of materials, including carbon steel, stainless steel, alloy steel, and nickel alloys, ensuring excellent mechanical strength, corrosion resistance, and high-temperature performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
180° Long Radius and 180° Short Radius Elbows offer several advantages for industrial piping systems. The Long Radius Elbow ensures smooth flow with minimal turbulence and pressure loss, making it ideal for applications requiring efficient fluid or gas movement. Its design reduces wear and tear on the system, extending service life. The Short Radius Elbow is perfect for installations with space constraints, allowing for sharp directional changes without compromising functionality. Both types are highly durable, resistant to corrosion, and capable of withstanding high pressures and temperatures, ensuring reliability in demanding environments.
Yes, custom sizes for 180 Deg Long Redius Elbow and 180 Deg Short Redius Elbow are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
On the other hand, **180° Short Radius Elbows** feature a curvature radius equal to the pipe diameter, allowing for sharper directional changes. They are particularly suited for tight piping configurations where space is at a premium, although they do create a slightly higher pressure drop and turbulence compared to their long radius counterparts. Short radius elbows are also available in various materials, offering durability, high tensile strength, and resistance to wear, corrosion, and extreme temperatures.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
