Zain Fittings, located in Surabaya, stands out as a reliable manufacturer and supplier of Monel 400 Buttweld Fittings in Jakarta, Indonesia. We pride ourselves on delivering top-notch piping components that excel in high-performance and corrosion-resistant applications. With a reputation for engineering excellence and a commitment to international quality standards, our Monel 400 buttweld fittings are perfect for marine, chemical, and high-temperature industrial settings. Designed for durability and strength, these fittings resist corrosive media, ensuring dependable connections even in the toughest conditions. As Jakarta’s industrial sector continues to grow, Zain Fittings is here to provide tailored solutions that meet a variety of project needs with precision and efficiency.
| Specification Properties: | Monel 400 Pipe Fittings |
| Cmmonly Used Fittings Types | End Cap, Stub End, Bend, Tee, Reducer, Cross, Adapter, 4 Wye, Elbow |
| Flange Connection Type | Clamp End / End Bell/ Threaded/ Weld |
| Thickness Tolerance: | Schedule 20S To Schedule XXS |
| Length: | Normal Pipe Size (1⁄₂”) to Normal Pipe Size (48”) |
| Manufacturer Of Fittings Dimension Types: | ANSI B16.28, MSS-SP-43 Type A, JIS B2312, ANSI B16.9, MSS-SP-43 Type B, JIS B2313 |
| Standard Chart : | JIS, NPT, ISO, DIN, EN |
| Pressure Rating Chart : | 150# To 2500#. |
| Materials List: | Bronze, Copper, Iron (Ductile/Cast), Carbon Steel, Inconel, Monel, Hastalloy, Alloy Steel, Brass, Titanium, Chrome-molybdenum, Cupro-Nickel 90/10 & 70/30, Nickel, Nickel Alloys, Tantalum, Stainless Steel. |
Monel 400 Buttweld Fittings are composed of approximately 63% nickel and 28-34% copper, with traces of iron, manganese, silicon, and carbon. This unique composition provides outstanding corrosion resistance in seawater, acidic, and alkaline environments. The mechanical properties include a tensile strength of up to 550 MPa and a yield strength of approximately 240 MPa, with excellent ductility and toughness. Monel 400 maintains its mechanical integrity at elevated temperatures and resists stress corrosion cracking, pitting, and crevice corrosion, making it ideal for high-pressure and high-temperature industrial applications.
| The Chemical Composition of Monel 400 Pipe Fittings, % | |
|---|---|
| Iron | ≤2.50 |
| Sulfur | ≤0.024 |
| Silicon | ≤0.50 |
| Copper | 28.0-34.0 |
| Nickel | ≥63.0 |
| Carbon | ≤0.30 |
| Manganese | ≤2.0 |
| Tensile Strength, minimum | Yield Strength, minimum | Elongation, minimum | Hardness | ||
|---|---|---|---|---|---|
| Mpa | ksi | Mpa | ksi | % | HB |
| 550 | 80 | 240 | 35 | 40 | 110-150 |
As a trusted source for Monel 400 Buttweld Fittings in Jakarta, Zain Fittings offers products made primarily from Nickel (63%) and Copper (30%), along with trace amounts of Iron, Manganese, and other elements. This distinctive nickel-copper alloy boasts exceptional resistance to seawater, acidic solutions, and alkalis. Monel 400 is known for its impressive mechanical properties, featuring a tensile strength of about 550 MPa and a yield strength of roughly 240 MPa. These qualities enable Monel 400 fittings to perform reliably in high-stress and corrosive environments, particularly where other materials might struggle.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Monel 400 Pipe Fittings | N04400 | 2.4360 | NU-30M | NiCu30Fe | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 |
Choose Monel 400 Buttweld Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Our Monel 400 Buttweld Fittings are widely utilized across Jakarta in various industries, including marine engineering, chemical processing, oil and gas, power generation, and heat exchangers. These fittings are specifically designed for environments that face high exposure to saltwater, sulfuric acid, hydrofluoric acid, and other aggressive chemicals. With excellent weldability, toughness, and thermal conductivity, Monel 400 fittings ensure secure, leak-free joints even under extreme operating conditions.
Yes, custom sizes for Monel 400 Buttweld Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id
Monel 400 Buttweld Fittings are widely used in industries requiring superior corrosion resistance and durability. In marine applications, they are ideal for seawater systems, desalination plants, and heat exchangers. The chemical processing industry relies on these fittings for handling acidic and alkaline solutions, while oil and gas industries use them in pipelines and offshore platforms. They are also utilized in power generation, aerospace, and heat exchanger systems where high strength and resistance to harsh environments are critical. Monel 400 ensures reliable performance in demanding and corrosive conditions.
