Zain Fittings is a top-notch manufacturer and supplier located in Surabaya, Indonesia, focusing on high-quality Monel Forged Fittings. These fittings are celebrated for their outstanding corrosion resistance, durability, and strength, making them perfect for tough industrial and marine settings. Zain Fittings prides itself on precision manufacturing and strict adherence to international standards, ensuring that their products are reliable and built to last. Commonly found in chemical processing, oil and gas, marine, and seawater applications, Monel Forged Fittings create secure, leak-proof connections. Their impressive performance in acidic and chloride-rich environments makes them a go-to choice for critical piping systems that require long-term reliability and high performance.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Monel Forged Fittings are mainly made up of 63% nickel, 28–32% copper, along with trace amounts of iron, manganese, and silicon. This unique blend guarantees exceptional corrosion resistance, particularly in seawater and acidic conditions, while also maintaining excellent mechanical properties. In terms of mechanics, these fittings boast a tensile strength of 550–690 MPa, yield strength of 220–350 MPa, and an elongation of 30–40%. They provide remarkable toughness, ductility, and dimensional stability, ensuring dependable performance even under high pressure, elevated temperatures, and chemically aggressive environments.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Zain Fittings is a leading supplier of Monel Forged Fittings in Jakarta, Indonesia. We offer an extensive range of Monel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Choose Monel Forged Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel Forged Fittings offer several key advantages, including exceptional corrosion resistance, particularly in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions, such as marine and chemical processing applications. Monel fittings maintain their strength and integrity at elevated temperatures, offering superior durability in high-stress environments. They also possess excellent weldability and machinability, making installation and customization easier. With their long-lasting performance and ability to withstand extreme conditions, Monel Forged Fittings provide reliable solutions for critical industrial applications.
Yes, custom sizes for Monel Forged Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id
These Monel Forged Fittings are widely utilized in industries that require high corrosion resistance and mechanical reliability. They are perfect for chemical processing systems, seawater piping, desalination plants, and marine applications. In the petrochemical, oil and gas, and high-performance industrial sectors, these fittings are designed to handle aggressive media and high-pressure situations. Additionally, they find their place in pumps, valves, heat exchangers, and critical piping components where leak-proof performance, durability, and a long service life are crucial. The combination of corrosion resistance, mechanical strength, and toughness makes Monel Forged Fittings a preferred choice in demanding applications.
