Zain Fittings, located in Surabaya, Indonesia, stands out as a top manufacturer and supplier of high-quality Carbon Steel P265GH Pipe Fittings. Known for their durability, strength, and ability to withstand high temperatures, these fittings are crafted to meet international standards, ensuring reliable performance even in tough industrial settings. The company utilizes cutting-edge manufacturing techniques and rigorous quality control measures to guarantee precise dimensions, exceptional mechanical properties, and long-lasting reliability. Catering to sectors like power generation, petrochemicals, oil and gas, and chemical processing, Zain Fittings provides Carbon Steel P265GH Pipe Fittings that consistently perform well in high-pressure and high-temperature situations.
| P265GH Carbon Steel Pipe Fittings size | P265GH Seamless Butt Weld Fittings : 1/2″ – 10″ P265GH Welded Butt Weld Fittings : 1/2″ – 48″ |
|---|---|
| CS P265GH Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| P265GH Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| P265GH Buttweld Pipe FittingsType | DN15-DN1200 |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A234 Gr P265GH Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A234 P265GH Buttweld Fitting |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| P265GH Carbon Steel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| EN 10253-1 P265GH Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | CS 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Carbon Steel P265GH Pipe Fittings are composed primarily of carbon, manganese, phosphorus, sulfur, and silicon, with a specific focus on maintaining a high level of strength and durability. The material is typically made up of around 0.18% carbon, 1.5% manganese, and a small amount of silicon. Its mechanical properties include a yield strength of 265 MPa and tensile strength ranging between 410-540 MPa, along with good weldability and formability. It is highly resistant to mechanical stress and thermal fatigue, making it ideal for high-pressure and high-temperature applications.
| Element | % by mass | Element | % by mass |
| Carbon (C) | ≤0.20 | Silicon (Si) | ≤0.40 |
| Manganese (Mn) | 0.80 to 1.40 | Phosphorous (P) (maximum) | 0.025 |
| Sulphur (S) (maximum) | 0.015 | Aluminium (Al) | <=0.020 |
| Nitrogen (N) | <=0.012 | Chromium (Cr) | <=0.30 |
| Copper (Cu) | <=0.30 | Molybdenum (Mo) | <=0.08 |
| Niobium (Nb) | <=0.020 | Nickel (Ni) | <=0.30 |
| Titanium (Ti) (maximum) | 0.03 | Vanadium (Vi) | <=0.02 |
| Nominal thickness (millimeter): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 410-530 | 400-530 | 390-530 |
These fittings are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon, with iron as the main component. This blend gives them impressive mechanical strength, ductility, and toughness, especially at elevated temperatures. Typically, they boast a tensile strength ranging from 410 to 550 MPa, a yield strength of 265 MPa, and an elongation of 20 to 25%. Their good weldability, impact resistance, and high-temperature performance make them perfect for applications in boilers, heat exchangers, and pressure vessels, where durability under stress is crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Carbon Steel P265GH Pipe Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Carbon Steel P265GH Pipe Fittings offer several advantages, including excellent strength and durability, making them ideal for high-pressure and high-temperature environments. Their high tensile strength ensures they can withstand mechanical stress, while their resistance to thermal fatigue enhances their longevity in demanding applications. Additionally, these fittings exhibit good weldability and formability, facilitating ease of installation and customization. They are also cost-effective, offering a balance of performance and affordability. With resistance to impact and corrosion, Carbon Steel P265GH Pipe Fittings ensure reliable, long-term operation in industries like petrochemical, oil & gas, and power generation.
Yes, custom sizes for Carbon Steel P265GH Pipe Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Spain UNE | Sweden SS | Poland PN | Czechia CSN | Austria ONORM | Russia GOST | Inter ISO | ||||||||||||||||||||||||||||||
| P265GH Flange |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Carbon Steel P265GH Pipe Fittings are extensively utilized in industries that demand reliable performance in high-temperature and high-pressure environments. You’ll find them in power plant piping, boilers, heat exchangers, chemical processing units, and refinery pipelines. They’re also ideal for pressure vessels, steam pipelines, and industrial process systems where maintaining structural integrity and ensuring leak-free connections are vital. With their blend of strength, durability, and cost-effectiveness, these fittings are a go-to choice for industrial piping solutions that require a long service life and dependable performance.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
