Zain Fittings, located in Surabaya, Indonesia, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Carbon Steel P235GH Pipe Fittings. These fittings are celebrated for their impressive strength, durability, and ability to withstand high temperatures, all while adhering to international standards for pressure and heat applications. By blending cutting-edge manufacturing technology with rigorous quality control, Zain Fittings ensures that their products are not only dependable but also precisely crafted. They cater to various industries, including power generation, oil and gas, petrochemical, and boiler manufacturing, providing Carbon Steel P235GH Pipe Fittings that excel in performance and long-lasting reliability, even in challenging environments.
| Size Range | Welded Fittings: 1/2″ – 48″ Seamless Fittings: 1/2″ – 10″ |
|---|---|
| Bending Radius | R=8D, 3D, 10D, 1D, 2D, 5D, 6D or Custom MSS Sp-43 |
| Elbows | Angle : 3D, 4D, 5D, 6D, 1.0D, 1.5D, 2.0D, 2.5D, 7D-40D . Standard: MSS SP-75 JISB2312 JISB2313, ASME B16.9, 22.5 deg, 30deg, 45 deg, 90 deg, DIN2605 JISB2311 BS, 180 deg, GB, ISO |
| Specialized manufacturer of | 90º Elbows, Tee, Stub End, Pipe Cap, Crosses, 45º Elbows, Reducers, Pipe Bend |
| Thickness | SCH 140, SCH 160, SCH10, SCH30, STD SCH40, SCH20, XS, SCH 80, SCH60, SCH 100, SCH 120, XXS |
| Dimensions | ASME/ANSI B16.9, BS4504, ASME B16.28, MSS-SP-43, BS4504, BS1560, BS10 |
| Manufacturing process | Press, Forge, Push, Cast, etc. |
| Origin & Mills | Japanese, Korean, European, Indian, USA, Ukraine, Russian |
| Type | DN15-DN1200 |
| Connection | Welding |
| Test Certificates | Raw Materials Certificate EN 10204/3.1B Third Party Inspection Report, etc |
The composition of Carbon Steel P235GH Pipe Fittings includes carbon, manganese, phosphorus, sulfur, and silicon, with iron as the primary element. This blend guarantees outstanding mechanical and thermal properties, making them perfect for high-temperature applications. With a tensile strength between 360–500 MPa, a yield strength of 235 MPa, and an elongation of 25%, these fittings boast excellent ductility, weldability, and impact resistance. They maintain their strength even under extreme pressure and temperature, making them ideal for high-performance piping systems.
| C | Si | Mn | Ni | P | S | Cr | Mo | V | N | Nb | Ti | Al | Cu | – |
| max 0.16 | max 0.35 | 0.6 – 1.2 | max 0.3 | max 0.025 | max 0.015 | max 0.3 | max 0.08 | max 0.02 | max 0.012 | max 0.02 | max 0.03 | max 0.02 | max 0.3 | Cr+Cu+Mo+Ni < 0.7 |
| Nominal thickness (mm): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 360-480 | 350-480 | 340-480 |
Zain Fittings is a leading supplier of Carbon Steel P235GH Pipe Fittings in Jakarta, Indonesia. We offer an extensive range of Carbon Steel P235GH Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Carbon Steel P235GH Pipe Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Carbon Steel P235GH pipe fittings offer numerous advantages, including excellent weldability, making them ideal for high-pressure and high-temperature environments. Their strong mechanical properties, such as a yield strength of 235 MPa and tensile strength up to 360 MPa, ensure reliability and durability. These fittings provide excellent corrosion resistance in various industrial applications, ensuring long-lasting performance. Additionally, they are cost-effective compared to other materials, offering a great balance between quality and price. Their versatility allows them to be used in a wide range of industries, including power generation, petrochemical, and HVAC systems.
Yes, custom sizes for Carbon Steel P235GH Pipe Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Belgium NBN | Spain UNE | China GB | Sweden SS | Poland PN | Czechia CSN | Finland SFS | Austria ONORM | Russia GOST | Inter ISO | India IS | |||||||||||||||||||||||||||||||
| P235GH |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nominal Pipe Size | Outside Diameter | Reducers | ||
|---|---|---|---|---|
|
Reduced from
(inches) |
(mm) |
(inches) |
Reduced to
(inches) |
Concentric & Eccentric Length
(inches) |
|
1/2 |
21.3 |
0.840 |
1/4 |
1 1/2 |
|
3/8 |
1 1/2 |
|||
|
3/4 |
26.7 |
1.050 |
3/8 |
2 |
|
1/2 |
2 |
|||
|
1 |
33.4 |
1.315 |
3/8 |
2 |
|
1/2 |
2 |
|||
|
3/4 |
2 |
|||
|
1 1/4 |
42.2 |
1.660 |
1/2 |
2 |
|
3/4 |
2 |
|||
|
1 |
2 |
|||
|
1 1/2 |
48.3 |
1.900 |
1/2 |
2 1/2 |
|
3/4 |
2 1/2 |
|||
|
1 |
2 1/2 |
|||
|
1 1/4 |
2 1/2 |
|||
|
2 |
60.3 |
2.375 |
3/4 |
3 |
|
1 |
3 |
|||
|
1 1/4 |
3 |
|||
|
1 1/2 |
3 |
|||
|
2 1/2 |
73.0 |
2.875 |
1 |
3 1/2 |
|
1 1/4 |
3 1/2 |
|||
|
1 1/2 |
3 1/2 |
|||
|
2 |
3 1/2 |
|||
|
3 |
88.9 |
3.500 |
1 |
3 1/2 |
|
1 1/2 |
3 1/2 |
|||
|
2 |
3 1/2 |
|||
|
2 1/2 |
3 1/2 |
|||
|
3 1/2 |
101.6 |
4.000 |
1 1/4 |
4 |
|
1 1/2 |
4 |
|||
|
2 |
4 |
|||
|
2 1/2 |
4 |
|||
|
3 |
4 |
|||
|
4 |
114.3 |
4.500 |
1 1/2 |
4 |
|
2 |
4 |
|||
|
2 1/2 |
4 |
|||
|
3 |
4 |
|||
|
3 1/2 |
4 |
|||
|
5 |
141.3 |
5.563 |
2 |
5 |
|
2 1/2 |
5 |
|||
|
3 |
5 |
|||
|
3 1/2 |
5 |
|||
|
4 |
5 |
|||
|
6 |
168.3 |
6.625 |
2 1/2 |
5 1/2 |
|
3 |
5 1/2 |
|||
|
3 1/2 |
5 1/2 |
|||
|
4 |
5 1/2 |
|||
|
5 |
5 1/2 |
|||
|
8 |
219.1 |
8.625 |
3 |
6 |
|
3 1/2 |
6 |
|||
|
4 |
6 |
|||
|
5 |
6 |
|||
|
6 |
6 |
|||
|
10 |
273.1 |
10.750 |
4 |
7 |
|
5 |
7 |
|||
|
6 |
7 |
|||
|
8 |
7 |
|||
|
12 |
323.9 |
12.750 |
5 |
8 |
|
6 |
8 |
|||
|
8 |
8 |
|||
|
10 |
8 |
|||
| Product range and theoretical weights (kg) | |||||||||
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
These fittings are widely utilized in industries that demand efficient handling of heat and pressure. Common applications include boilers, heat exchangers, pressure vessels, and piping systems in power plants. They are also found in refineries, petrochemical facilities, and steam pipelines, thanks to their resilience against fluctuating temperatures and corrosive environments. Carbon Steel P235GH Pipe Fittings ensure reliable performance in both low- and high-pressure situations, providing leak-free connections and maintaining structural integrity. Their affordability, strength, and thermal stability make them a go-to choice for industrial piping and power generation systems.
