Zain Fittings, located in Surabaya, Indonesia, is a well-respected manufacturer and supplier of **Alloy Steel F9 Forged Fittings** in Jakarta. They specialize in providing high-strength, reliable piping solutions that are essential for critical industrial applications. With a reputation for precision engineering and a commitment to international quality standards, Zain Fittings produces forged fittings using top-notch F9 alloy steel, ensuring outstanding performance even under high temperatures and pressures. These fittings are crafted to offer a long service life and are resistant to mechanical stress and thermal fatigue. Catering to various industries throughout Jakarta, Zain Fittings supplies durable and cost-effective forged fittings that meet the rigorous demands of power plants, refineries, and the petrochemical sector.
| Specification : | ASTM A182 F9 Forged Fittings |
|---|---|
| Size | Threaded Fittings = ½” – 4” |
| Pressure Rating | Threaded Fittings = Class 2000, Class 3000, Class 6000 |
| Type Of Pipe systems | 45 Deg Elbow, Equal tee, Full Coupling, Reducing Tee, 90 Deg Elbow, Half Coupling, Street Elbow, Bull Plug, Boss, Union (Male/Female), Lateral Outlet, 45 Lateral Tee, Equal Cross, Pipe Cap, Branch Outlets, Swage Nipple. |
| Thread Connections | ASME B16.11 (Socket Welding and Threaded) Fittings, MSS-SP-83 (Class Unions) Fittings, ASME B16.3 (Malleable Iron Fittings) Fittings, ASME B16.4 ( Gray Iron Fittings) Fittings, ASME B16.39 (Malleable Iron Unions) Fittings, ASME B16.34 (Valves — Flanged) Fittings, ASME B16.39 (Malleable Iron Pipe Unions, 150#, 250#, Or 300#) Fittings. |
| Standards | ASME B16.11 (American Standard), Bs3799, MSS SP 79, JIS B2302, MSS-SP-97 (Threadolet), MSS-SP-83 (Union), ASME B36.19 (Nipple) |
| Types Of Thread | NPT Fittings, BSPP Fittings, BSPT Fittings, PF Fittings, PT Fittings, MPT |
| Applications | Oil and Gas Chemical Power station Water Pipeline Noncritical Applications Fire Protection |
| Advantages Of | Simple Usage Easy installation Economic as cheaper |
As a prominent **Alloy Steel F9 Forged Fittings Manufacturer and Supplier in Jakarta**, Zain Fittings utilizes a chromium-molybdenum alloy steel that typically contains about 9% Chromium and 1% Molybdenum. This specific composition significantly boosts the material’s resistance to oxidation, high temperatures, and corrosion. The mechanical properties of Alloy Steel F9 include a tensile strength of roughly 585 MPa and a yield strength of around 415 MPa, making it ideal for applications that experience thermal cycling and heavy mechanical loads. These fittings maintain their structural integrity even in extreme service conditions, providing exceptional durability and safety.
| Gr | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F9 Forged Fittings | 0.15 | 0.3 – 0.6 | 0.5 – 1 | 0.03 | 0.03 | 8 – 10 | 0.9 – 1.1 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| ASTM A182 F9 Forged Fittings | 380 | 585 | 20 |
Zain Fittings is a leading supplier of Alloy Steel F9 Forged Fittings in Jakarta, Indonesia. We offer an extensive range of Alloy Steel F9 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel F9 Forged Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Zain Fittings’ **Alloy Steel F9 Forged Fittings** are widely used across Jakarta’s industrial landscape, including sectors like power generation, oil and gas, chemical processing, and heat exchangers. These fittings are particularly suited for high-temperature applications, especially in steam and pressure systems, where thermal stability and creep resistance are crucial. Their forged design not only enhances strength but also improves resistance to fatigue, ensuring reliability in demanding environments.
Yes, custom sizes for Alloy Steel F9 Forged Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
| STANDARD | UNS | WERKSTOFF NR. | Trade Name |
| ASTM A182 F9 Forged Fittings | K90941 | 1.7386 | 9Cr-1Mo |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A | Center to End 45 Deg Elbow C | O.D. of Band H | Min. Wall Thick. G | Length of Thread. Minimum (1) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| Normal Pipe Size | A | B | QTY | Weight In KG |
|---|---|---|---|---|
| ¼ | 0.81 | 0.88 | 160 | 0.20 |
| ⁄ | 0.97 | 1.00 | 130 | 0.26 |
| ½ | 1.12 | 1.31 | 100 | 0.57 |
| ¾ | 1.31 | 1.5 | 75 | 0.71 |
| 1 | 1.5 | 1.81 | 40 | 1.08 |
| 1 ¼ | 1.75 | 2.19 | 25 | 1.68 |
| 1 ½ | 2.00 | 2.44 | 18 | 2.38 |
| 2 | 2.38 | 2.97 | 10 | 3.55 |
| 2 ½ | 3.00 | 3.62 | 4 | 6.22 |
| 3 | 3.38 | 4.31 | 2 | 10.36 |
| 4 | 4.19 | 5.75 | 1 | 23.91 |
Alloy Steel F9 Forged Fittings are widely used in industries requiring high-strength and durable components. These fittings are ideal for high-pressure and high-temperature applications in oil and gas, petrochemical, power generation, and chemical processing industries. They are commonly used in steam pipelines, heat exchangers, pressure vessels, and refinery equipment. Their excellent resistance to corrosion, oxidation, and thermal stress makes them suitable for offshore drilling, power plants, and other critical systems where reliable, leak-proof connections are essential for operational safety and efficiency.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
