Zain Fittings stands out as a top-notch manufacturer and supplier of premium **Alloy Steel F22 Forged Fittings** right in the heart of Jakarta, Indonesia. With a strong focus on engineering excellence and product reliability, Zain Fittings provides forged fittings that are built to handle the tough demands of high-pressure and high-temperature environments. Thanks to their state-of-the-art production facilities and rigorous quality control measures, every Alloy Steel F22 fitting they produce meets international standards like ASME, ASTM, and ANSI. Catering to sectors such as oil and gas, power generation, and petrochemicals, Zain Fittings is your go-to source for reliable forged solutions for critical piping systems, both in Indonesia and beyond.
| Specification : | ASTM A182 F22 Forged Fittings |
|---|---|
| Size | Threaded Fittings = ½” – 4” |
| Pressure Rating | Threaded Fittings = Class 2000, Class 3000, Class 6000 |
| Type Of Pipe systems | 45 Deg Elbow, Equal tee, Full Coupling, Reducing Tee, 90 Deg Elbow, Half Coupling, Street Elbow, Bull Plug, Boss, Union (Male/Female), Lateral Outlet, 45 Lateral Tee, Equal Cross, Pipe Cap, Branch Outlets, Swage Nipple. |
| Thread Connections | ASME B16.11 (Socket Welding and Threaded) Fittings, MSS-SP-83 (Class Unions) Fittings, ASME B16.3 (Malleable Iron Fittings) Fittings, ASME B16.4 ( Gray Iron Fittings) Fittings, ASME B16.39 (Malleable Iron Unions) Fittings, ASME B16.34 (Valves — Flanged) Fittings, ASME B16.39 (Malleable Iron Pipe Unions, 150#, 250#, Or 300#) Fittings. |
| Standards | ASME B16.11 (American Standard), Bs3799, MSS SP 79, JIS B2302, MSS-SP-97 (Threadolet), MSS-SP-83 (Union), ASME B36.19 (Nipple) |
| Types Of Thread | NPT Fittings, BSPP Fittings, BSPT Fittings, PF Fittings, PT Fittings, MPT Fittings |
| Applications | Oil and Gas Chemical Power station Water Pipeline Noncritical Applications Fire Protection |
| Advantages Of | Simple Usage Easy installation Economic as cheaper |
Alloy Steel F22 Forged Fittings are made with a balanced composition of chromium (1.00-1.50%), molybdenum (0.87-1.13%), carbon (0.05-0.15%), manganese (0.30-0.60%), silicon (0.15-0.35%), and trace amounts of phosphorus and sulfur. This blend enhances their strength, toughness, and resistance to corrosion and high temperatures. These fittings exhibit excellent mechanical properties, including a tensile strength of 415-585 MPa, a yield strength of 205 MPa, and elongation of around 20%. Their superior durability and impact resistance make them ideal for demanding industrial applications.
| Gr | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F22 Forged Fittings | 0.15 | 0.3 – 0.6 | 0.5 – 1 | 0.03 | 0.03 | 8 – 10 | 0.9 – 1.1 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| ASTM A182 F22 Forged Fittings | 380 | 585 | 20 |
These Alloy Steel F22 Forged Fittings are crafted from a low-alloy chromium-molybdenum steel, featuring about 2.25% chromium and 1% molybdenum. This unique blend gives the fittings remarkable mechanical strength, impressive creep resistance, and exceptional performance even in high temperatures and corrosive settings. Typically, they boast a tensile strength ranging from 415 to 585 MPa and a yield strength between 205 and 275 MPa. Such characteristics make F22 forged fittings perfect for environments that experience thermal stress, pressure changes, and aggressive media. Their toughness and weldability are also top-notch, ensuring reliable performance in high-stress piping assemblies, especially in steam and power generation systems.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel F22 Forged Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Alloy Steel F22 Forged Fittings offer several advantages, including exceptional strength and durability, making them ideal for high-pressure and high-temperature applications. Their excellent resistance to corrosion, oxidation, and wear ensures longevity in harsh environments. The fittings provide superior weldability and machinability, allowing easy installation and customization. With a balanced chemical composition, they deliver reliable performance in critical applications such as power plants, petrochemical industries, and marine systems. Additionally, their cost-effectiveness and compatibility with diverse industrial systems make Alloy Steel F22 Forged Fittings a preferred choice for demanding operations.
Yes, custom sizes for Alloy Steel F22 Forged Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
| STANDARD | UNS | WERKSTOFF NR. | Trade Name |
| ASTM A182 F22 Forged Fittings | K21590 | 1.7380 | 2-1/4Cr-1/2Mo-Vd |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A | Center to End 45 Deg Elbow C | O.D. of Band H | Min. Wall Thick. G | Length of Thread. Minimum (1) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| Normal Pipe Size | A | B | QTY | Weight In KG |
|---|---|---|---|---|
| ¼ | 0.81 | 0.88 | 160 | 0.20 |
| ⁄ | 0.97 | 1.00 | 130 | 0.26 |
| ½ | 1.12 | 1.31 | 100 | 0.57 |
| ¾ | 1.31 | 1.5 | 75 | 0.71 |
| 1 | 1.5 | 1.81 | 40 | 1.08 |
| 1 ¼ | 1.75 | 2.19 | 25 | 1.68 |
| 1 ½ | 2.00 | 2.44 | 18 | 2.38 |
| 2 | 2.38 | 2.97 | 10 | 3.55 |
| 2 ½ | 3.00 | 3.62 | 4 | 6.22 |
| 3 | 3.38 | 4.31 | 2 | 10.36 |
| 4 | 4.19 | 5.75 | 1 | 23.91 |
Alloy Steel F22 Forged Fittings are a staple in industries that require strength, durability, and heat resistance. These fittings shine in power plants, oil refineries, chemical processing units, and offshore platforms, where components must endure extreme conditions. You’ll often find them in high-pressure steam lines, heat exchangers, boilers, and reactor piping systems. Their forged design guarantees a high level of integrity and performance, making them a trusted choice for critical applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
