Zain Fittings, located in Surabaya, Indonesia, stands out as a top manufacturer and supplier of Incoloy 825 forged fittings, serving clients in Midland, UK. Known for their precision engineering and rigorous quality control, Zain Fittings ensures that their products meet international standards, offering durability, reliability, and the ability to withstand extreme industrial conditions. Their Incoloy 825 forged fittings are specifically designed to endure high-pressure and high-temperature environments while providing excellent corrosion resistance. By blending cutting-edge manufacturing techniques with skilled craftsmanship, Zain Fittings delivers customized solutions for industries that need strong and reliable piping systems, earning a solid reputation in the global market.
| ASTM B564 Incoloy Alloy 825 Forged Fittings Specification | |
|---|---|
| Specifications | ASTM B564 / ASME SB564 |
| Standards | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8″ NB to 4″ NB (Socketweld & Screwed-Threaded) |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Type | Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT |
| Gr.825 Incoloy Alloy Forged Pipe Fittings Chemical Composition | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Grade | Ni | C | Fe | Si | Mn | S | Al | Ti | Cu | Cr | Mb |
| Incoloy 825 | 38.0 – 46.0 | 0.05 max | 22.0 min | 0.5 max | 1.0 max | 0.03 max | 0.2 max | 0.6 – 1.2 | 1.5 – 3.0 | 19.5 – 23.5 | 2.5 – 3.5 |
| Incoloy 825 Forged Fittings Mechanical Properties | |||||
|---|---|---|---|---|---|
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000, MPa -550 | Psi – 32,000, MPa – 220 | 30 % |
| Incoloy ASTM B564 Forged Fittings Equivalent Grades | ||||||||
|---|---|---|---|---|---|---|---|---|
| STANDARD | UNS | WNR NO. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 825 | N08825 | 2.4858 | NFE30C20DUM | NiCr21Mo | NCF 825 | NA 16 | ЭП703 | XH38BT |
Incoloy 825 forged fittings are primarily made of nickel, iron, and chromium, with trace amounts of molybdenum and copper. This distinctive composition gives them remarkable resistance to oxidation and corrosion, especially in acidic and chloride-heavy environments. On the mechanical side, these fittings boast high tensile strength, good ductility, and toughness across a wide temperature range. They maintain their structural integrity during thermal cycling and resist stress corrosion cracking. The combination of mechanical strength and chemical stability makes Incoloy 825 forged fittings perfect for demanding industrial applications where both pressure resistance and longevity are crucial.
Zain Fittings is a leading supplier of Incoloy 825 Forged Fittings in Jakarta, Indonesia. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 825 Forged Fittings from Zain Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 825 forged fittings offer outstanding resistance to corrosion, especially in acidic and oxidizing environments, making them ideal for chemical processing and marine applications. Their high nickel content prevents stress-corrosion cracking, while molybdenum and copper enhance resistance to pitting and crevice corrosion. These fittings maintain excellent mechanical strength and stability across a broad temperature range. They are also highly durable and versatile, supporting easy fabrication and welding. Reliable and long-lasting, Incoloy 825 forged fittings are perfect for demanding industries like oil and gas, pollution control, and power generation systems.
Yes, custom sizes for Incoloy 825 Forged Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id
These fittings are commonly found in the chemical processing, petrochemical, and marine industries due to their outstanding corrosion resistance and mechanical strength. They excel at handling acids, alkalis, and seawater, as well as in high-temperature settings. In piping systems, heat exchangers, and reactors, they provide dependable connections even under extreme conditions. Moreover, they are also utilized in power generation, pollution control, and pharmaceutical manufacturing, where material failure can result in expensive downtime. Their durability and performance make them an essential choice for various applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
