Zain Fittings, located in Surabaya, Indonesia, is a reliable manufacturer and supplier of Incoloy 800, 800H, and 800HT Buttweld Fittings for clients in Midland, UK. Known for their precision engineering and commitment to international quality standards, Zain Fittings provides durable and corrosion-resistant solutions that are perfect for demanding industrial applications. The company merges advanced manufacturing techniques with rigorous quality control to produce fittings that guarantee reliability and performance in high-temperature and high-pressure settings. Their dedication to excellence and a customer-centric approach has made Zain Fittings a go-to partner for industries in need of top-notch Incoloy buttweld fittings.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
Incoloy 800, 800H, and 800HT buttweld fittings are mainly made from nickel, iron, and chromium, which gives them outstanding resistance to oxidation and corrosion. These alloys are known for their high strength and stability at elevated temperatures, with the 800H and 800HT variants specifically crafted for improved creep and thermal resistance. Typical mechanical properties include tensile strength ranging from 485 to 620 MPa, yield strength between 205 and 275 MPa, and elongation rates of 30 to 40%, depending on the specific grade. Their exceptional thermal and mechanical properties make them ideal for applications that involve prolonged exposure to high temperatures without sacrificing structural integrity.
Zain Fittings is a leading supplier of Incoloy 800/ 800H/ 800HT Buttweld Fittings in Jakarta, Indonesia. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 800/ 800H/ 800HT Buttweld Fittings from Zain Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 800, 800H, and 800HT buttweld fittings offer numerous advantages, including excellent high-temperature strength and superior resistance to oxidation and carburization. These alloys maintain stability and structural integrity in extreme environments, making them ideal for chemical processing, power plants, and heat exchangers. The addition of titanium in 800H and 800HT improves creep resistance and enhances long-term performance. Their outstanding weldability ensures easy fabrication, while high resistance to corrosion and stress cracking ensures longevity. These alloys provide durability, reducing maintenance and downtime in high-temperature industrial applications.
| Nominal PipeSize | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| (inches) | – | Long Radius | Short Radius | Long Radius | Long Radius | |||
| (mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | 7/16 | 2 1/4 | 1 11/16 | ||
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Yes, custom sizes for Incoloy 800/ 800H/ 800HT Buttweld Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
Incoloy 800/800H/800HT buttweld fittings are commonly utilized in the chemical processing, petrochemical, power generation, and refinery sectors due to their resistance to high-temperature corrosion and oxidation. They are perfect for piping systems that transport corrosive fluids, steam, and heat exchangers. These fittings play a crucial role in boilers, superheaters, and reactors, ensuring safety and durability under extreme operating conditions. Their ability to maintain mechanical strength at elevated temperatures makes them suitable for continuous high-heat processes, while their corrosion resistance means less maintenance is required, making them a smart choice for any industrial application.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
