Hastelloy Pipe Fittings Manufacturer and Supplier In Jakarta, Indonesia

Zain Fittings, located in Surabaya, Indonesia, has built a solid reputation as a reliable manufacturer and supplier of top-notch Hastelloy pipe fittings for clients in Midland, UK. Known for their precision engineering and strict adherence to international standards, Zain Fittings provides products that guarantee durability, corrosion resistance, and dependable performance in tough industrial settings. Their dedication to excellence, prompt delivery, and competitive pricing has made them a go-to partner for industries in need of high-quality Hastelloy solutions. With a strong emphasis on innovation and customer satisfaction, Zain Fittings is continuously enhancing its status as a leading provider of alloy-based pipe fittings around the globe.

Hastelloy Buttweld Elbow In Indonesia, ASTM B366 Hastelloy Alloy Pipe Fittings United kingdom, Hastelloy Stub End Jakarta, Hastelloy Reducing Tee Surabaya, Hastelloy Pipe Fittings in Bekasi, Hastelloy Buttweld Fittings Surabaya, ASME SB366 Hastelloy® Alloy Pipe Cap Bandung, Indonesia.

Hastelloy Pipe Fittings Specification

Specification : ASTM B366 / ASME SB366

Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

ASME B16.9 : standard for – Factory-Made Wrought Buttwelding Fittings

ASME B16.25 : Buttwelding Ends

ASME B16.28 : standard for – Butt-Welded Short Radius Elbows & Returns Bends

MSS SP-43 : Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications

Size Range : ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100)

Seamless Butt Weld Fitting Size : 1/2″ – 10″

Welded Butt Weld Fittings Size : 1/2″ – 48″

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Type : Seamless / Welded / Fabricated.

Hastelloy pipe fittings are primarily made from nickel, molybdenum, and trace amounts of iron and cobalt, giving them remarkable resistance to corrosion and oxidation. These alloys maintain their structural integrity at both high and low temperatures, boasting impressive tensile strength, yield strength, and hardness. Hastelloy is particularly resistant to pitting, stress corrosion cracking, and chemical attacks from harsh environments, including acids and chlorides. Its mechanical properties ensure longevity and reliable performance in challenging conditions, making it perfect for use in chemical processing, marine applications, and industrial systems where durability and corrosion resistance are crucial.

Hastelloy Pipe Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 – 16.50	4.00 – 7.00	15.00 – 17.00	0.04 max

Hastelloy Pipe Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790	Psi – 52,000 , MPa – 355	40 %

Equivalent Grades for Hastelloy Pipe Fittings

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–
Hastelloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760

Hastelloy 90 deg Elbow In Indonesia, Hastelloy 45 deg. Elbow United kingdom, Hastelloy Reducer, ANSI B16.9 Hastelloy Buttweld Pipe Fittings Suppliers in Jakarta, Hastelloy Seamless Pipe Fittings Manufacturers Surabaya, Hastelloy Pipe Bend in Bekasi, Hastelloy Pipe Fittings Price List in Surabaya, Hastelloy Pipe Elbow Suppliers Bandung, Hastelloy Buttweld Cross In Indonesia, Hastelloy Welded Pipe Fittings Exporter in Jakarta, Indonesia.

Largest Hastelloy Pipe Fittings Supplier in Jakarta, Indonesia

Zain Fittings is a leading supplier of Hastelloy Pipe Fittings in Jakarta, Indonesia. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Hastelloy Pipe Fittings Dimensions Standard

Nominal Pipe Size	All Fittings	All Fittings	All Fittings	Elbows/ Tees	180° Return Bends	180° Return Bends	180 Deg Return Bends	Reducers	Caps
NPS	O.D. at Bevel (1), (2)	I.D. at End (1), (3), (4)	Wall Thickness (3)	Centre-to-End Dimension A,B,C,M	Centre-to-Centre O	Back-to-Face K	Alignment of Ends U	Overall Length H	Overall Length E
½ to 2½	0.06 -0.03	0.03	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
3 to 3 ½	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
4	0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.12
5 to 8	0.09 -0.06	0.06	Not less than 87.5% of nominal thickness	0.06	0.25	0.25	0.03	0.06	0.25
10 to 18	0.16 -0.12	0.12	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
20 to 24	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.09	0.38	0.25	0.06	0.09	0.25
26 to 30	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.12	…	…	…	0.19	0.38
32 to 48	0.25 -0.19	0.19	Not less than 87.5% of nominal thickness	0.19	…	…	…	0.19	0.38

Why Choose Hastelloy Pipe Fittings from Zain Fittings?

Hastelloy Pipe Fittings from Zain Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

wide range of Hastelloy pipe fittings in a variety of size In U, wall thicknesses, dimensions and tolerance to meet your project’s needs—including pipe fittings in dimension as per ASME/ANSI B16.9, ASME B16.25, ASME B16.28, ASME B16.49, MSS-SP-43 Fittings / weight & thickness of Hastelloy pipe fittings.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Hastelloy pipe fittings offer numerous advantages, including outstanding corrosion resistance against harsh chemicals, oxidizing agents, and reducing environments. They excel in high-temperature applications and provide exceptional durability and strength, ensuring long-lasting performance. Hastelloy resists stress corrosion cracking, pitting, and crevice corrosion, making it ideal for demanding industries like chemical processing, marine engineering, and power generation. Their superior weldability and fabrication ease enable precise custom solutions. With a proven ability to withstand extreme conditions, Hastelloy pipe fittings are a reliable choice for critical applications requiring high performance and dependability.

Types of Hastelloy Pipe Fittings

Are Custom Sizes Available for Hastelloy Pipe Fittings?

Yes, custom sizes for Hastelloy Pipe Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.

Hastelloy Buttweld Elbow In Indonesia, ASTM B366 Hastelloy Alloy Pipe Fittings United kingdom, Hastelloy Stub End Jakarta, Hastelloy Reducing Tee Surabaya, Hastelloy Pipe Fittings in Bekasi, Hastelloy Buttweld Fittings Surabaya, ASME SB366 Hastelloy® Alloy Pipe Cap Bandung, Indonesia.

Application Industry of Hastelloy Pipe Fittings

Hastelloy pipe fittings are extensively utilized in the chemical, petrochemical, and pharmaceutical sectors due to their ability to endure highly corrosive environments. They excel at handling acids, chlorine, and other aggressive chemicals, ensuring safety and reliability within systems. These fittings are also commonly found in marine and offshore applications, where resistance to saltwater corrosion is vital. Industries such as power generation, pollution control, and heat exchanger systems benefit from Hastelloy’s exceptional strength and thermal stability. Additionally, they find applications in aerospace and high-tech industries that demand corrosion-resistant materials.
