Zain Fittings, located in Surabaya, Indonesia, stands out as a top manufacturer and supplier of high-quality Alloy 20 Buttweld Fittings. These fittings are celebrated for their remarkable corrosion resistance, strength, and durability, crafted to meet international standards for tough industrial applications. By blending cutting-edge manufacturing technology with strict quality control, Zain Fittings ensures that their products boast precise dimensions, excellent mechanical properties, and long-lasting reliability. They cater to various industries, including chemical processing, petrochemical, power generation, and marine engineering, providing Alloy 20 Buttweld Fittings that excel in harsh, corrosive, and high-temperature settings.
| 20 Pipe Fittings Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Alloy 20 Pipe Fittings size | 20 Seamless Butt Weld Fittings : 1/2″ – 10″ 20 Welded Butt Weld Fittings : 1/2″ – 48″ |
| Alloy 20 Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Alloy 20 Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| 20 Buttweld Pipe FittingsType | DN15-DN1200 |
| ASTM B366 20 Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM B366 Alloy 20 Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM B366 20 Buttweld Fitting |
| ASTM B366 20 Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| Alloy 20 Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| SA 366 20 Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | Alloy UNS N08020, 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
The Alloy 20 Buttweld Fittings are primarily made from nickel, chromium, and copper, with a thoughtful mix of molybdenum, iron, and manganese. This specialized composition grants them exceptional resistance to sulfuric acid, oxidizing agents, and other harsh chemicals. On the mechanical side, these fittings showcase a tensile strength ranging from 550 to 750 MPa, a yield strength of 300 to 450 MPa, and an elongation of 25 to 35%. They are known for their excellent weldability, toughness, and resistance to pitting, crevice corrosion, and stress corrosion cracking, making them perfect for critical chemical and industrial piping systems.
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
Zain Fittings is a leading supplier of Alloy 20 Buttweld Fittings in Jakarta, Indonesia. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Alloy 20 Buttweld Fittings from Zain Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Alloy 20 Buttweld Fittings offer several key advantages, making them ideal for demanding applications. Their exceptional corrosion resistance, particularly to sulfuric acid and other aggressive chemicals, ensures long-lasting durability in harsh environments. Alloy 20 provides excellent mechanical properties, such as high strength, enhanced stress corrosion cracking resistance, and superior weldability. These fittings are highly resistant to pitting and crevice corrosion, making them ideal for industries like chemical processing, pharmaceuticals, and food processing. Their reliability and performance in extreme conditions reduce maintenance costs and extend the lifespan of piping systems.
| Standard Code | Standard Name |
| ANSI ASME SA-366 | Forged Durimet pipe fittings |
| ANSI ASME B16.9 | Factory-Made wrought steel pipe fittings |
| ANSI ASME B16.28 | Wrought steel butt-welding short radius elbows and returns |
| ISO 5251 | Alloy butt-welding fittings |
| MSS SP-43 | Wrought Alloy butt-welding fittings |
| MSS SP-75 | Forging butt-welding fittings |
| German Steel Pipe Fittings Standard | |
| DIN 2605 | Steel butt-welding pipe fittings.elbows and bends |
| DIN 2615 | Steel butt-welding pipe fittings.tees |
| DIN 2616 | Steel butt-welding pipe fittings.reducers |
| DIN 2617 | Steel butt-welding pipe fittings.caps |
| Japanese Steel Pipe Fittings Standard | |
| JIS B2311 | Universal steel butt-welding pipe fittings |
| JIS B2312 | Steel butt-welding pipe fittings |
| JIS B2313 | Steel plate butt-welding pipe fittings |
| Other Steel Pipe Fittings Standard | |
| EN 1025 | 3 Butt-welding pipe fittings |
Yes, custom sizes for Alloy 20 Buttweld Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
Alloy 20 Buttweld Fittings find extensive use in industries that demand high-strength and corrosion-resistant piping solutions. You’ll often see them in chemical and pharmaceutical plants, acid handling systems, desalination plants, heat exchangers, and marine equipment. They’re also well-suited for pipelines, pressure vessels, and process piping that face aggressive chemical environments. With their combination of durability, corrosion resistance, and long service life, these fittings are the go-to choice for demanding industrial applications where reliability, safety, and operational efficiency are paramount.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
